Description
Overview
The MEI Talos T6S2-U10MUS is a U.S.-currency MDB bill validator designed for vending, kiosk, and amusement machines. Part of the Crane MEI Talos T6 Series, it replaces the discontinued AE26S2-U10MUS and offers faster validation, improved optical accuracy, and a durable gear-driven transport system for long-term reliability.
Featuring the Talos S-Bezel (Mid-Entry) and a 1000-note up-stacker cassette, this model operates on 24 V DC / 34 V DC MDB power. It is ideal for standard vending doors requiring a mid-height bill entry point. The T6S2-U10MUS combines Crane’s proven performance with Talos modular construction, advanced optics, and easy field serviceability for maximum uptime.
Key Features
- Accepts U.S. $1–$20 bills with 4-way optical validation
- Standard MDB interface (24 V DC / 34 V DC)
- Replaces legacy AE26S2-U10MUS
- S-Bezel (Mid-Entry) for standard vending door installations
- Up-stacker with 1000-note cassette for high-capacity operation
- Advanced anti-counterfeit and anti-stringing protection
- Upgradeable firmware via USB or handheld programmer
- Quick-release stacker and modular service design
- Rugged gear-driven mechanism for heavy-duty use
Technical Specifications
| Currency | U.S. Dollar (USD) |
|---|---|
| Interface | MDB Protocol |
| Bezel Type | S-Bezel (Talos Mid-Entry Up-Stacker) |
| Stacker Orientation | Upward |
| Stacker Capacity | Up to 1000 notes (removable cassette) |
| Operating Voltage | 24 V DC / 34 V DC |
| Bill Insertion | 4-way acceptance (any orientation) |
| Firmware Update | USB or handheld programmer |
| Operating Temperature | 0 °C – 50 °C (32 °F – 122 °F) |
Model Breakdown
| Code | Meaning | Description |
|---|---|---|
| T | Series | Talos Series — Crane MEI’s latest validator platform with modular design and enhanced optics. |
| 6 | Family | T6 Series — direct successor to AE26xx models, offering improved performance and reliability. |
| S | Bezel / Configuration | Talos S-Bezel (Mid-Entry) — designed for up-stacker use in standard vending door mounts. |
| 2 | Power Configuration | 24 V DC / 34 V DC MDB power standard for vending, kiosk, and amusement systems. |
| U10 | Stacker / Currency Variant | Up-stacker with 1000-note cassette for U.S. currency ($1–$20 denominations). |
| MUS | Build Code | U.S. standard MDB build (M-series mainboard) with Talos firmware. |
Summary:
The MEI Talos T6S2-U10MUS replaces the AE26S2-U10MUS, delivering a mid-entry S-Bezel, 1000-note up-stacker, and Crane MEI’s reliable optical validation for MDB vending and amusement applications.
BillAcceptors.us is an authorized Crane MEI distributor with over 30 years of experience, offering the best prices and repair support.
Technical Specifications
| Brand | Crane MEI |
| Model Series | Talos T6 |
| Voltage | 34v MDB |
| Supported Protocols | MDB |
| Stacker Capacity | 1000 Bills |
| Bezel Type | MEI Upstacker Mid-Entry "S" |
| Denomination Acceptance | $1-$20 |
| Condition | New |
