Description
Overview
The MEI Talos T681-D5EUS is a U.S.-currency 110 V AC bill validator from the Crane MEI Talos T6 Series, engineered as the direct replacement for the AE2681-D5EUS. It combines Crane’s proven validation technology with faster note acceptance, enhanced optical security, and a modular frame for simplified field service.
Featuring a High-Visibility Compact D-Bezel and an Down-Stacker configuration with a 500-note cassette, the T681-D5EUS operates on 110 V AC. It’s ideal for legacy vending, kiosk, and amusement systems that require AC-powered compatibility with modern Crane MEI performance.
Key Features
- Accepts U.S. $1–$20 bills with 4-way optical validation
- 110 V AC pulse / parallel interface for legacy systems
- Replaces legacy AE2681-D5EUS
- High-Visibility Compact D-Bezel for enhanced customer guidance and lighting
- Down-Stacker with 500-note cassette capacity
- Advanced anti-counterfeit and anti-stringing protection
- Upgradeable firmware via USB or handheld programmer
- Quick-release stacker for tool-free maintenance
Technical Specifications
| Currency | U.S. Dollar (USD) |
|---|---|
| Interface | 110 V AC Pulse / Parallel / Legacy |
| Bezel Type | High-Visibility Compact D-Bezel |
| Stacker Orientation | Downward (Down-Stacker) |
| Operating Voltage | 110 V AC ± 10 % |
| Stacker Capacity | 500 notes (interchangeable cassette) |
| Bill Insertion | 4-way acceptance (any orientation) |
| Operating Temperature | 0 °C – 50 °C (32 °F – 122 °F) |
Model Breakdown
| Code | Meaning | Description |
|---|---|---|
| T | Series | Talos Series — Crane MEI’s modern validator platform with advanced optics and modular servicing. |
| 6 | Model Family | T6 Series — direct replacement for AE26xx and AE28xx validators. |
| 8 | Bezel Type | High-Visibility Compact D-Bezel for vending and amusement applications. |
| 1 | Power Configuration | 110 V AC input for legacy non-MDB installations. |
| D5 | Stacker / Capacity | Down-Stacker with 500-note cassette capacity. |
| EUS | Build Code | U.S. E-series mainboard configuration with Talos firmware. |
Summary:
The MEI Talos T681-D5EUS replaces the AE2681-D5EUS, featuring a High-Visibility Compact D-Bezel, Down-Stacker design, 500-note cassette, and 110 V AC operation for kiosk and amusement systems.
BillAcceptors.us is an authorized Crane MEI distributor with over 30 years of experience, offering the best prices and repair support.
Technical Specifications
| Brand | Crane MEI |
| Model Series | Talos T6 |
| Voltage | 110v AC |
| Supported Protocols | Pulse, Serial |
| Stacker Capacity | 500 Bills |
| Bezel Type | MEI Compact Downstacker "8" |
| Denomination Acceptance | $1-$20 |
| Condition | New |
