Description
Overview
The MEI Talos T651-U5EUS is a U.S.-currency 110 V AC bill validator designed for legacy vending, kiosk, and amusement machines. As part of the Crane MEI Talos T6 Series, it replaces the discontinued AE2651-U5EUS model, offering faster note acceptance, enhanced counterfeit detection, and a simplified modular service design.
Built on Crane MEI’s advanced Talos platform, the T651-U5EUS integrates high-resolution optical sensors and a durable gear-driven transport system for high-volume performance. Its standard Talos bezel provides a universal front-entry interface, and its pulse compatibility allows direct plug-and-play replacement of legacy AE26xx units.
Key Features
- Accepts U.S. $1–$20 bills with advanced optical validation
- Pulse/Parallel interface for vending, kiosk, and amusement systems
- Replaces legacy AE2651-U5EUS
- Standard Talos bezel for front-entry vending applications
- Enhanced anti-stringing and counterfeit protection
- Quick-release stacker and modular transport assembly
- Field-upgradeable firmware via USB or handheld programmer
- Durable gear-driven mechanism for extended service life
Technical Specifications
| Currency | U.S. Dollar (USD) |
|---|---|
| Interface | Pulse/Parallel Protocol |
| Bezel Type | Fitted "5" bezel |
| Operating Voltage | 110 V AC |
| Stacker Capacity | Up to 500 notes (up-stacker configuration) |
| Bill Insertion | 4-way acceptance (any orientation) |
| Firmware Update | USB or handheld programmer |
| Operating Temperature | 0 °C – 50 °C (32 °F – 122 °F) |
Model Breakdown
| Code | Meaning | Description |
|---|---|---|
| T | Series | Talos Series — Crane MEI’s latest validator platform featuring improved optics, security, and modular construction. |
| 6 | Model Family | T6 Series — direct replacement for the AE26xx validator family. |
| 5 | Bezel Type | CPI fitted "5" bezel |
| 1 | Power Configuration | 110 V AC input for legacy non-MDB installations. |
| U5 | Stacker Configuration | Up-stacker with 500-note cassette |
| EUS | Build Code | U.S. E-series mainboard configuration with Talos firmware. |
Summary:
The MEI Talos T651-U5EUS replaces the AE2651-U5EUS, delivering faster validation, 500-note up-stacker capacity, and complete pulse compatibility for car wash, kiosk, and amusement applications.
BillAcceptors.us is an authorized Crane MEI distributor with over 30 years of experience, offering the best prices and repair support.
Technical Specifications
| Brand | Crane MEI |
| Model Series | Talos T6 |
| Voltage | 110v AC |
| Supported Protocols | Pulse, Serial |
| Stacker Capacity | 500 Bills |
| Bezel Type | Mei Fitted "5" |
| Denomination Acceptance | $1-$20 |
| Condition | New |
